DEEP PICTURES WITH CMOS CAMERA

Posted by Paul On July - 2 - 2018

I've upgraded my imaging capabilities with a CMOS camera with the ability to cool the sensor.

ZWO ASI294MC Pro Cooled Color Astronomy Camera

Sony IMX294CJK CMOS Sensor

The Sony IMX294CJK is the first internal imaging sensor for astronomical cameras to support the Type 4/3 format, producing the pixel output necessary for 4K at 120 frame/s (in ADC 10-bit output mode, the ASI294MC can run up to 25 fps at 4K format base on USB3.0 bandwidth). Additionally, the ASI294MC Pro uses large pixels to achieve SNR1s of 0.14 1x* which is comparable to the ASI224's (0.13 1x*) value.

Exceptional Low Illumination Performance

A large-size optical system along with the extension of the pixel area to 4.63 µm allows for exceptional low-illumination performance. This results in a sensor that is optimal for astrophotography applications requiring low-illumination operation.

Additional Highlights

The ASI294MC Pro features 14-Bit ADC and can achieve a dynamic range of 13 stops, an improvement over even the ASI1600.

Full well capacity is 63700e, three times the capacity of the ASI1600. Even when exposed for long periods, bright stars won't saturate. The ASI294MC Pro can reach a higher SNR (signal to noise ratio) with one individual exposure.

256 MB DDR3 memory buffer enables better data transfer stability with no amp-glow, an issue generated by the slow speed data transfer during readout when connected with a USB2.0 port.

A back-illuminated type sensor, the IMX294 has a very high QE estimated to be more than 75%.

USB 3.0 port supplies 5 gb of bandwidth to make running the ASI294MC at 16 fps (14bit, normal mode) or 19 fps (10bit, high speed mode) at full 11.7 MP resolution possible.

The USB 2.0 hub connects with a variety of accessories like a filter wheel, guide camera, and electronic focuser. Your cable can be better managed with the USB2.0 hub. Includes two short 0.5 m USB2.0 cables to power the source of the hub via an external supply when connected.

The ASI294MC Pro and ASI1600 Pro have identical mechanics. The chamber is sealed by four screws. This structure has been through rigorous testing and is known to be very stable. Even in extremely humid conditions, the ASI294MC Pro still works as normal without dew problems.



This is a slide presentation (4 minutes) of images I took with my telescope at Y Mountain Observatory.  This illustrates what you can’t normally see.  There are Heavenly Father’s creations all around us, that testify of Him in our world that you can see, if you have eyes to see.

CLICK ON THE LINK BELOW

https://youtu.be/1qRrCRNL-CU



Now on to the pictures…

The Crescent Nebula (also known as NGC 6888, Caldwell 27, Sharpless 105) is an emission nebula in the constellation Cygnus, about 5000 light-years away from Earth. It was discovered by William Herschel in 1792. It is formed by the fast stellar wind from the Wolf-Rayet star WR 136 (HD 192163) colliding with and energizing the slower moving wind ejected by the star when it became a red giant around 250,000 to 400,000 years ago. The result of the collision is a shell and two shock waves, one moving outward and one moving inward. The inward moving shock wave heats the stellar wind to X-ray-emitting temperatures.

It is a rather faint object located about 2 degrees SW of Sadr. For most telescopes it requires a UHC or OIII filter to see. Under favorable circumstances a telescope as small as 8 cm (with filter) can see its nebulosity. Larger telescopes (20 cm or more) reveal the crescent or a Euro sign shape which makes some to call it the "Euro sign nebula". (Wikipedia)

Imaging Data:

Imaging Data:

Date:   5/19/2021

Exposure= 300s for a total of 1 hours 35 minutes

Binning = 1×1

Camera Temperature= -10 deg C

Camera Gain= 120

Filter= STC Astro Duo-Narrowband Filter

Camera: ASI294MC PRO in Hyperstar configuration.



The Dumbbell Nebula (also known as Apple Core Nebula, Messier 27, or NGC 6853) is a planetary nebula in the constellation Vulpecula, at a distance of about 1227 light-years. This object was the first planetary nebula to be discovered; by Charles Messier in 1764. At its brightness of visual magnitude 7.5 and its diameter of about 8 arcminutes, it is easily visible in binoculars, and a popular observing target in amateur telescopes.

Imaging Data:

Date: 8/19/19

Exposure=       30s x 420 of which 250 were used

Binning = 1×1

Gain = 120

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

The Triangulum Galaxy  (Messier 33) is a spiral galaxy 2.73 million light-years (ly) from Earth in the constellation Triangulum. It is catalogued as Messier 33 or NGC 598. The Triangulum Galaxy is the third-largest member of the Local Group of galaxies, behind the Milky Way and the Andromeda Galaxy. It is one of the most distant permanent objects that can be viewed with the naked eye.

The galaxy is the smallest spiral galaxy in the Local Group and it is believed to be a satellite of the Andromeda Galaxy due to their interactions, velocities, and proximity to one another in the night sky. It also has an H II nucleus. (Wikipedia)

Imaging Data:

Date: 9/20-21/2021

Exposure= 72x300s & 36x600s for a total of 12 hours of which 25 exposures and 3 hours were used

Binning = 1×1

Gain = 125

Camera Temperature=  0 deg C (600second exposures) & -10 deg C (300 second exposures)

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

Messier 34 (M34) is a bright, large open cluster located in the northern constellation Perseus.



The cluster lies at an approximate distance of 1,500 light years from Earth and has an apparent magnitude of 5.5. It has the designation NGC 1039 in the New General Catalogue.



Messier 34 is pretty easy to find in the sky and its stars can be resolved even in 10×50 binoculars. The cluster is located just to the north of the imaginary line drawn from Algol (Beta Persei), the second brightest star in Perseus, to Almach (Gamma Andromedae), the third brightest star in the neighbouring constellation Andromeda.

Imaging Data:

Date: 11/19/2018

Exposure= 240s x 152

Binning = 2×2

Gain = 200

Camera Temperature= -10 deg C

Camera = ZWO ASI294 MC Pro in Hyperstar Position

The Rosette Nebula (also known as Caldwell 49) is a large spherical H II region (circular in appearance) located near one end of a giant molecular cloud in the Monoceros region of the Milky Way Galaxy. The open cluster NGC 2244 (Caldwell 50) is closely associated with the nebulosity, the stars of the cluster having been formed from the nebula's matter.

The complex has the following NGC designations:

NGC 2237 – Part of the nebulous region (Also used to denote whole nebula)

NGC 2238 – Part of the nebulous region

NGC 2239 – Part of the nebulous region (Discovered by John Herschel)

NGC 2244 – The open cluster within the nebula (Discovered by John Flamsteed in 1690)

NGC 2246 – Part of the nebulous region

The cluster and nebula lie at a distance of some 5,000 light-years from Earth and measure roughly 130 light years in diameter. The radiation from the young stars excites the atoms in the nebula, causing them to emit radiation themselves producing the emission nebula we see. The mass of the nebula is estimated to be around 10,000 solar masses.

A survey of the nebula with the Chandra X-ray Observatory has revealed the presence of numerous new-born stars inside optical Rosette Nebula and studded within a dense molecular cloud. Altogether, approximately 2500 young stars lie in this star-forming complex, including the massive O-type stars HD 46223 and HD 46150, which are primarily responsible for blowing the ionized bubble. Most of the ongoing star-formation activity is occurring in the dense molecular cloud to the south east of the bubble.

A diffuse X-ray glow is also seen between the stars in the bubble, which has been attributed to a super-hot plasma with temperatures ranging from 1 to 10 million K. This is significantly hotter than the 10,000 K plasmas seen in HII regions, and is likely attributed to the shock-heated winds from the massive O-type stars.

On April 16, 2019 the Oklahoma Legislature passed HB1292 making the Rosette Nebula as the official state astronomical object. Oklahoma Governor Kevin Stitt signed it into law April 22, 2019.

INAGING DATA

Date    1/5/19

Exposure         120 sec

No. of lights    130

Gain     200

Binning            2X2

Camera           ZWO ASI294MC Pro using Hyperstar V

Filter    STC Astro Duo-Narrowband


1/5/2019 NGC 7000 The North America Nebula

EXP: 60s x 90

Temp: -10C

Gain: 200

Bin: 2×2

Post Processed in IP then PS

Camera: ASI294MC-PRO with STC Astro Duo-Narrowband Filter

Celestron 1100HD with Hyperstar V





IC 405 (also known as the Flaming Star Nebula, SH 2-229, or Caldwell 31) is an emission and reflection nebula in the constellation Auriga, surrounding the bluish star AE Aurigae. It shines at magnitude +6.0. Its celestial coordinates are RA  05h 16.2m dec +34° 28′. It surrounds the irregular variable star AE Aurigae and is located near the emission nebula IC 410, the open clusters M38 and M36, and the K-class star Iota Aurigae. The nebula measures approximately 37.0' x 19.0', and lies about 1,500 light-years away from Earth. The nebula is about 5 light-years across.

Taken on Jan 29, 30, Feb 1

Exp=120 sec x 254 for 8 h 28 m

Bin = 1×1

Temp=-10 C

Gain=120

Telescope Celestron 1100 Edge HD

Camera ZWO ASI294MC-PRO with Hyperstar V

Filter STC Astro Duo-Narrowband

Mount 10Micron GM1000HPS on pier

Processed using Images Plus and PhotoShop

I imaged the North American nebula on June30th.  It consists of 118 60 sec exposures (1 hour 58 minutes) at a gain of 200, Binning=1×1, T=0 deg C.  It was post processed using  Pixinsight and Photoshop and doesn’t contain darks or flats.

The North America Nebula (NGC 7000 or Caldwell 20) is an emission nebula in the constellation Cygnus, close to Deneb (the tail of the swan and its brightest star). The remarkable shape of the nebula resembles that of the continent of North America, complete with a prominent Gulf of Mexico.

The North America Nebula is large, covering an area of more than four times the size of the full moon; but its surface brightness is low, so normally it cannot be seen with the unaided eye. Binoculars and telescopes with large fields of view (approximately 3°) will show it as a foggy patch of light under sufficiently dark skies. (Wikipedia)

Tis is a reprocess of images that I took on Jan 7,2019. I reprocessed the data using Images Plus, PixInsight, and PhotoShop.

The Orion Nebula (also known as Messier 42, M42, or NGC 1976) is a diffuse nebula situated in the Milky Way, being south of Orion's Belt in the constellation of Orion. It is one of the brightest nebulae, and is visible to the naked eye in the night sky. M42 is located at a distance of 1,344 ± 20 light years and is the closest region of massive star formation to Earth. The M42 nebula is estimated to be 24 light years across. It has a mass of about 2,000 times that of the Sun. Older texts frequently refer to the Orion Nebula as the Great Nebula in Orion or the Great Orion Nebula. (Wikipedia)

Imaging Data
Image M42
Date 1/7/19
Exposure 120s
Number of Lights 30
Darks Y
Flats Y
Gain 120
Binning 1X1
Imaging Software Sequence Generator Pro
Camera ZWO ASI294MC Pro
Cooling Temp Deg C -10
Filter Astronomik L-2 UV-IR Blocking Filter
Telescope Celestron 1100HD SCT
Mount 10MICRON GM1000HPS
Focuser MicroTouch Focuser



7/21/2019

The Eagle Nebula (catalogued as Messier 16 or M16, and as NGC 6611, and also known as the Star Queen Nebula and The Spire) is a young open cluster of stars in the constellation Serpens. Both the "Eagle" and the "Star Queen" refer to visual impressions of the dark silhouette near the center of the nebula,[3][4] an area made famous as the "Pillars of Creation" imaged by the Hubble Space Telescope. The nebula contains several active star-forming gas and dust regions, including the aforementioned Pillars of Creation.

The Eagle Nebula is part of a diffuse emission nebula, or H II region, which is catalogued as IC 4703. This region of active current star formation is about 7000 light-years distant. A spire of gas that can be seen coming off the nebula in the northeastern part is approximately 9.5 light-years or about 90 trillion kilometers long.

Imaging Data
Image M16
Date 7/19-20/2019
Exposure 60s
Number of Lights 233
Darks Y
Flats Y
Gain 200
Binning 1X1
Imaging Software Sequence Generator Pro
Camera ZWO ASI294MC Pro
Cooling Temp Deg C 0
Filter STC Astro Duo-Narrowband
Telescope Celestron 1100HD SCT
Mount 10MICRON GM1000HPS
Focuser MicroTouch Focuser

8/3/2019 I've reprocessed images I took on 2/1/19 of IC 1848 the Soul Nebula.

The Soul Nebula is an emission nebula located in Cassiopeia. Several small open clusters are embedded in the nebula: CR 34, 632, and 634 (in the head) and IC 1848 (in the body). The object is more commonly called by the cluster designation IC 1848.

Small emission nebula IC 1871 is present just left of the top of the head, and small emission nebulae 670 and 669 are just below the lower back area.

The galaxies Maffei 1 and Maffei 2 are both nearby the nebula, although light extinction from the Milky Way makes them very hard to see. Once thought to be part of the Local Group, they are now known to belong to their own group- the IC 342/Maffei Group.

This complex is the eastern neighbor of IC1805 (Heart Nebula) and the two are often mentioned together as the "Heart and Soul".

This image is composed of 76 180 seconds images taken in the Hyperstar configuration.



12/6/2019 Last night I imaged IC 1805 the Heart Nebula.  The Heart Nebula, IC 1805 lies some 7500 light years away from Earth and is located in the Perseus Arm of the Galaxy in the constellation Cassiopeia. It was discovered by William Herschel on 3 November 1787. This is an emission nebula showing glowing ionized hydrogen gas and darker dust lanes.

The very brightest part of this nebula (the knot at the western edge) is separately classified as NGC 896, because it was the first part of this nebula to be discovered.

The nebula's intense red output and its configuration are driven by the radiation emanating from a small group of stars near the nebula's center. This open cluster of stars known as Melotte 15 contains a few bright stars nearly 50 times the mass of our Sun, and many more dim stars that are only a fraction of our Sun's mass.

Imaging Data:

Exposure= 30s x 360 of which 269 were used

Binning = 1×1

Camera Temperature= -10 deg C

Filter= STC Astro Duo-Narrowband Filter



8/21/2019  On 8/19/2019 I imaged NGC 6960 or The Veil Nebula is a cloud of heated and ionized gas and dust in the constellation Cygnus.

It constitutes the visible portions of the Cygnus Loop, a supernova remnant, many portions of which have acquired their own individual names and catalogue identifiers. The source supernova was a star 20 times more massive than the Sun, which exploded around 8,000 years ago. The remnants have since expanded to cover an area of the sky roughly 3 degrees in diameter (about 6 times the diameter, or 36 times the area, of the full Moon).  The distance to the nebula is not precisely known, but Far Ultraviolet Spectroscopic Explorer (FUSE) data supports a distance of about 1,470 light-years.

The Hubble Space Telescope captured several images of the nebula. The analysis of the emissions from the nebula indicate the presence of oxygen, sulfur, and hydrogen. The Cygnus Loop is also a strong emitter of radio waves and x-rays.

Imaging Data:

Exposure= 30s x 240 of which 202 were used

Binning = 1×1

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

This is a set of images taken on August 21, 2019 of IC 1396.
The Elephant's Trunk Nebula is a concentration of interstellar gas and dust within the much larger ionized gas region IC 1396 located in the constellation Cepheus about 2,400 light years away from Earth. The piece of the nebula shown here is the dark, dense globule IC 1396A; it is commonly called the Elephant's Trunk nebula because of its appearance at visible light wavelengths, where there is a dark patch with a bright, sinuous rim. The bright rim is the surface of the dense cloud that is being illuminated and ionized by a very bright, massive star (HD 206267) that is just to the east of IC 1396A. The entire IC 1396 region is ionized by the massive star, except for dense globules that can protect themselves from the star's harsh ultraviolet rays.

The Elephant's Trunk Nebula is now thought to be a site of star formation, containing several very young (less than 100,000 yr) stars that were discovered in infrared images in 2003. Two older (but still young, a couple of million years, by the standards of stars, which live for billions of years) stars are present in a small, circular cavity in the head of the globule. Winds from these young stars may have emptied the cavity.

The combined action of the light from the massive star ionizing and compressing the rim of the cloud, and the wind from the young stars shifting gas from the center outward lead to very high compression in the Elephant's Trunk Nebula. This pressure has triggered the current generation of protostars. (Wikipedia)

Imaging Data:
Exposure= 120s x 180 of which 75 were used for a total of 150 minutes
Gain=120
Binning = 1×1
Camera Temperature= 0 deg C
Filter= STC Astro Duo-Narrowband Filter
Camera: ASI294MC PRO in Hyperstar configuration.



8/29/2019

The Pleiades , also known as the Seven Sisters and Messier 45, are an open star cluster containing middle-aged, hot B-type stars located in the constellation of Taurus. It is among the nearest star clusters to Earth and is the cluster most obvious to the naked eye in the night sky.

The cluster is dominated by hot blue and luminous stars that have formed within the last 100 million years. Reflection nebulae around the brightest stars were once thought to be left over material from the formation of the cluster but are now considered likely to be an unrelated dust cloud in the interstellar medium through which the stars are currently passing.

Computer simulations have shown that the Pleiades were probably formed from a compact configuration that resembled the Orion Nebula. Astronomers estimate that the cluster will survive for about another 250 million years, after which it will disperse due to gravitational interactions with its galactic neighborhood. (Wikipedia)

Imaging Data:

August 23, 2019

Exposure= 30s x 300 of which 273 were used

Gain=120

Binning = 1×1

Camera Temperature= 0 deg C

Filter= LP UV/IR

Camera= ASI294MC PRO in Hyperstar mode



9/2/2019

I imaged NGC 281 on August 31, 2019. It is composed of 360 x 60s images.

NGC 281, IC 11 or Sh2-184 is a bright emission nebula and part of an H II region in the northern constellation of Cassiopeia and is part of the Milky Way's Perseus Spiral Arm. This 20×30 arcmin sized nebulosity is also associated with open cluster IC 1590, several Bok globules and the multiple star, B 1. It collectively forms Sh2-184, spanning over a larger area of 40 arcmin. A recent distance from radio parallaxes of water masers at 22 GHz made during 2014 is estimated it lies 2.82±0.20 kpc. (9200 ly.) from us. Colloquially, NGC 281 is also known as the Pacman Nebula for its resemblance to the video game character.

Imaging Data:

Date: 8/31/19

Exposure= 60s x 360

Binning = 1×1

Gain = 120

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

10/4/2019

This image of the North sky Milky Way is composed of 10 x 120 second images.  These were taken at a very dark site about 12 miles North of Moab Utah on Sept 30, 2019.  I used my Star Adventurer tracker on my tripod to track with.  The camera I used was my Nikon D850 coupled with my Tamron SP 15-30mm lens.  The ISO was set to 800.

Picture saved with settings applied.

10/4/2019

This image of the South of the sky Milky Way is composed of 29 x 120 second images.  These were taken at a very dark site about 12 miles North of Moab Utah on Sept 30, 2019.  I used my Star Adventurer tracker on my tripod to track with.  The camera I used was my Nikon D850 coupled with my Tamron SP 15-30mm lens.  The ISO was set to 800.

The Omega Nebula is (Messier 17) between 5,000 and 6,000 light-years from Earth and it spans some 15 light-years in diameter. The cloud of interstellar matter of which this nebula is a part is roughly 40 light-years in diameter and has a mass of 30,000 solar masses. The total mass of the Omega Nebula is an estimated 800 solar masses.

It is considered one of the brightest and most massive star-forming regions of our galaxy. Its local geometry is similar to the Orion Nebula except that it is viewed edge-on rather than face-on.

The open cluster NGC 6618 lies embedded in the nebulosity and causes the gases of the nebula to shine due to radiation from these hot, young stars; however, the actual number of stars in the nebula is much higher – up to 800, 100 of spectral type earlier than B9, and 9 of spectral type O, plus over a thousand stars in formation on its outer regions. It is also one of the youngest clusters known, with an age of just 1 million years.

The luminous blue variable HD 168607, located in the south-east part of the Omega nebula, is generally assumed to be associated with it; its close neighbor, the blue hypergiant HD 168625, may be too.

The Swan portion of M17, the Omega Nebula in the Sagittarius nebulosity is said to resemble a barber's pole. (Wikipedia)

Imaging Data:

Date: 8/14/19

Exposure= 30s x 120 of which 67 were used

Binning = 1×1

Gain + 200

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

Processed in DSS (lights only) then PS

NGC 7023

The Iris Nebula, also known as NGC 7023 and Caldwell 4, is a bright reflection nebula and Caldwell object in the constellation Cepheus. NGC 7023 is actually the cluster within the nebula, LBN 487, and the nebula is lit by a magnitude +7 star, SAO 19158. It shines at magnitude +6.8. It is located near the Mira-type variable star T Cephei, and near the bright magnitude +3.23 variable star Beta Cephei (Alphirk). It lies 1,300 light-years away and is six light-years across. (Wikipedia)

Imaging Data:

Image:                         NGC 7023

Date                            6/10/19, 8/22/19,  7/9/20, 7/11/20

Exposure:                    120 sec & 180 sec for 12 hours of images

Binning = 1×1

Gain = 120

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

Messier 102 (also known as M102 or the Spindle Galaxy) is a galaxy listed in the Messier Catalogue that has not been identified unambiguously. Its original discoverer Pierre Méchain later said that it was a duplicate observation of Messier 101, but more recent historical evidence favors that it is NGC 5866,[ although other galaxies have been suggested as possible identities. (Wikipedia)

Imaging Data:

Date: 11/7/14

Gain = 1600

Camera = Canon 60Da

11-26-2019

The Andromeda Galaxy , also known as Messier 31, or NGC 224 and originally the Andromeda Nebula, is a spiral galaxy approximately 780 kiloparsecs (2.5 million light-years) from Earth, and the nearest major galaxy to the Milky Way. The galaxy's name stems from the area of the Earth's sky in which it appears, the constellation of Andromeda.

The virial mass of the Andromeda Galaxy is of the same order of magnitude as that of the Milky Way, at a trillion solar masses. The Andromeda Galaxy has a diameter of about 220,000 light-years, making it the largest member of the Local Group at least in terms of extension, if not mass.

The number of stars contained in the Andromeda Galaxy is estimated at one trillion (1×1012), or roughly twice the number estimated for the Milky Way.

The Milky Way and Andromeda galaxies are expected to collide in ~4.5 billion years, merging to form a giant elliptical galaxy or a large lenticular galaxy. With an apparent magnitude of 3.4, the Andromeda Galaxy is among the brightest of the Messier objects making it visible to the naked eye from Earth on moonless nights, even when viewed from areas with moderate light pollution. (Wikipedia)

Imaging Data

Date:                          11/18/2019

Exposure:                   30 seconds

Number of Lights:       320

Gain:                          120

Camera Type:            ZWO ZSI294MC PRO

Filter:                         Astronomik UV-IR

Temp:                        -10 deg C

Telescope:                Celestron 1100HS SCT

Mount:                       10Micron

12-21-2019

This is an image of  NGC 2264 which is a combination of the Cone Nebula and the Christmas Tree Nebula.  This is located about 2600 light years from us.

Imaging Data:

Date: 12/19/19

Exposure:       30seconds x 540 of which 154 where used

Binning:          1×1

Gain:               120

Camera Temperature: -10 deg C

Filter:              STC Astro Duo-Narrowband Filter

Camera:          ASI294MC PRO in Hyperstar position

Mount :           10Micron GM1000HPS on pier

5/7/2020

This is a combination of M81 and M82 taken on the morning of 5/7/2020.  It is from a stack of 40 exposures of 300 seconds each, stacked in Images Plus, processed with PixInsight and finally Photoshop.

Messier 81 (also known as NGC 3031 or Bode's Galaxy) is a spiral galaxy about 12 million light-years away in the constellation Ursa Major. Due to its proximity to Earth, large size and active galactic nucelus, which harbors a supermassive black hole, Messier 81 has been studied extensively by professional astronomers.

Messier 82 (also known as NGC 3034, Cigar Galaxy or M82) is the prototype nearby starburst galaxy about 12 million light-years away in the constellation Ursa Major. The starburst galaxy is five times brighter than the whole Milky Way and one hundred times brighter than our galaxy's center.

In 2005, the Hubble Space Telescope revealed 197 young massive clusters in the starburst core. The average mass of these clusters is around 2×105 M, hence the starburst core is a very energetic and high-density environment. Throughout the galaxy's center, young stars are being born 10 times faster than they are inside our entire Milky Way Galaxy.

Imaging Data:

Date: 5/7/2020

Exposure=       300s x 40 of which 33 were used

Binning = 1×1

Gain = 120

Camera Temperature= -10 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

5/7/2020

Messier 3 (M3 or NGC 5272) is a globular cluster of stars in the northern constellation of Canes Venatici. It was discovered on May 3, 1764, and was the first Messier object to be discovered by Charles Messier himself. Messier originally mistook the object for a nebula without stars. This mistake was corrected after the stars were resolved by William Herschel around 1784. Since then, it has become one of the best-studied globular clusters. Identification of the cluster's unusually large variable star population was begun in 1913 by American astronomer Solon Irving Bailey and new variable members continue to be identified up through 2004.



Many amateur astronomers consider it one of the finest northern globular clusters, following only Messier 13. M3 has an apparent magnitude of 6.2,[5] making it a difficult naked eye target even with dark conditions. With a moderate-sized telescope, the cluster is fully defined. It can be a challenge to locate through the technique of star hopping, but can be found by looking almost exactly halfway along an imaginary line connecting the bright star Arcturus to Cor Caroli. Using a telescope with a 25 cm (9.8 in) aperture, the cluster has a bright core with a diameter of about 6 arcminutes and spans a total of 12 arcminutes.

This cluster is one of the largest and brightest, and is made up of around 500,000 stars. It is estimated to be 8 billion years old. It is located at a distance of about 33,900 light-years away from Earth (Wikipedia)

Imaging Data:

Date: 5/7/2020

Exposure= 300s x 40 of which 7 were used for a total of 35 minutes

Gain=120

Binning = 1×1

Camera Temperature=-10 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera: ASI294MC PRO in Hyperstar configuration

The Sombrero Galaxy (also known as Messier Object 104, M104 or NGC 4594) is a galaxy in the constellation Virgo found 9.55 megaparsecs (31.1 million light-years) from Earth. The galaxy has a diameter of approximately 15 kiloparsecs (49,000 light-years), 30% the size of the Milky Way. It has a bright nucleus, an unusually large central bulge, and a prominent dust lane in its inclined disk. The dark dust lane and the bulge give this galaxy the appearance of a sombrero hat. Astronomers initially thought that the halo was small and light, indicative of a spiral galaxy, but the Spitzer Space Telescope found that the dust ring around the Sombrero Galaxy is larger and more massive than previously thought, indicative of a giant elliptical galaxy. The galaxy has an apparent magnitude of +8.0, making it easily visible with amateur telescopes, and it is considered by some authors to be the galaxy with the highest absolute magnitude within a radius of 10 megaparsecs of the Milky Way. Its large bulge, its central supermassive black hole, and its dust lane all attract the attention of professional astronomers. Wikipedia

Imaging Data:

Date: 5/8/2020

Exposure=       300s x 17

Binning = 1×1

Gain = 120

Camera Temperature= -10 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

Messier 106 (also known as NGC 4258) is an intermediate spiral galaxy in the constellation Canes Venatici. It was discovered by Pierre Méchain in 1781. M106 is at a distance of about 22 to 25 million light-years away from Earth. M106 contains an active nucleus classified as a Type 2 Seyfert, and the presence of a central supermassive black hole has been demonstrated from radio-wavelength observations of the rotation of a disk of molecular gas orbiting within the inner light-year around the black hole. NGC 4217 is a possible companion galaxy of Messier 106. A Type II supernova was observed in M106 in May 2014. Wikipedia

Imaging Data:

Date: 5/8/2020

Exposure=       300s x 59

Binning = 1×1

Gain = 120

Camera Temperature= -10 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

The Pinwheel Galaxy (also known as Messier 101, M101 or NGC 5457) is a face-on spiral galaxy distanced 21 million light-years (six megaparsecs) away from Earth in the constellation Ursa Major. Discovered by Pierre Méchain on March 27, 1781, it was communicated to Charles Messier who verified its position for inclusion in the Messier Catalogue as one of its final entries.

M101 is a large galaxy, with a diameter of 170,000 light-years. By comparison, the Milky Way has a diameter of 100,000 light years. It has around a trillion stars, twice the number in the Milky Way. It has a disk mass on the order of 100 billion solar masses, along with a small central bulge of about 3 billion solar masses. Wikipedia

Imaging Data:

Date: April 21, 24, 28 and May 9 2020

Exposure=       30s x 478

                        60s x 420

                        120s x 232

                        These were reduced from 1130 exposures to 387 which represented the best.

The final images represented 5 hours and 16 minutes which resulted in the final picture.

Binning = 1×1

Camera Temperature= -10 deg C

Filters= STC Astro Duo-Narrowband Filter & Astronomik UV-IP Blocking Filter

5/24/2020

The Whirlpool Galaxy, also known as Messier 51, and NGC 5194, is an interacting grand-design spiral galaxy with a Seyfert 2 active galactic nucleus. It lies in the constellation Canes Venatici, and was the first galaxy to be classified as a spiral galaxy. Its distance is estimated to be 23 million light-years away from Earth.

The galaxy and its companion, NGC 5195, are easily observed by amateur astronomers, and the two galaxies may be seen with binoculars. The Whirlpool Galaxy has been extensively observed by professional astronomers, who study it to understand galaxy structure (particularly structure associated with the spiral arms) and galaxy interactions. (Wikipedia)

Date: 6/28/19 & 5/23/20

Exposure=       60s x 64 (6/28/19)

                        60s x 289 (5/23/20)

Total exposure time 2 h 58m

Binning = 1×1

Gain = 120

Camera Temperature= 0 deg C

Filter= UV/IR FILTER 6/28/19

STC Astro Duo-Narrowband Filter 5/23/20

Camera = ASI294MC PRO in Hyperstar position

6/7/2020 Here is Messier 39 which I imaged some time back:

Messier 39 or M39, also known as NGC 7092, is an open cluster of stars in the constellation of Cygnus, positioned two degrees to the south of the star Pi Cygni and around 9° east-northeast of Deneb. The cluster was discovered by Guillaume Le Gentil in 1749, then Charles Messier added it to his catalogue in 1764. When observed in a small telescope at low power the cluster shows around two dozen members, but it is best observed with binoculars. It has a total integrated magnitude (brightness) of 5.5 and spans an angular diameter of 29 arcminutes – about the size of the full Moon. M39 is at a distance of about 1,010 light-years (311 parsecs) from the Sun.

This cluster has an estimated mass of 232 M and a linear tidal radius of 8.6±1.8 pc. Of the 15 brightest components, six form binary star systems with one more suspected. HD 205117 is a probable eclipsing binary system with a period of 113.2 days that varies by 0.051 in visual magnitude. Both members appear to be subgiant stars. There are at least five chemically peculiar stars in the cluster and ten[ suspected short-period variable stars. (Wikipedia)

Imaging Data:

Date: 6/27/19

Exp = 30s x 480 of which 377 were used

Gain = 200

Temp = 0 Deg C

Binning = 1×1

Camera = ZWO AST294MC Pro in Hyperstar position

Filter = Astronomik L-2 UV-IR Blocking Filter

IC 5146 (also Caldwell 19, Sh 2-125, and the Cocoon Nebula) is a reflection/emission nebula and Caldwell object in the constellation Cygnus. The NGC description refers to IC 5146 as a cluster of 9.5 mag stars involved in a bright and dark nebula. The cluster is also known as Collinder 470. It shines at magnitude +10.0/+9.3/+7.2. Its celestial coordinates are RA  21h 53.5m, dec +47° 16′. It is located near the naked-eye star Pi Cygni, the open cluster NGC 7209 in Lacerta, and the bright open cluster M39. The cluster is about 4,000 ly away, and the central star that lights it formed about 100,000 years ago; the nebula is about 12 arcmins across, which is equivalent to a span of 15 light years. WIKIPEDIA

Imaging Data:

Date: 6/27/2020

Exposure=       120s x 170 of which 139 were used

Binning = 1×1

Gain = 120

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position

NGC 4565 (also known as the Needle Galaxy or Caldwell 38) is an edge-on spiral galaxy about 30 to 50 million light-years away in the constellation Coma Berenices. It lies close to the North Galactic Pole and has a visual magnitude of approximately 10. It is known as the Needle Galaxy for its narrow profile. First recorded in 1785 by William Herschel, it is a prominent example of an edge-on spiral galaxy. Wikipedia

Imaging Data:

Date: 6/21/2020

Exposure= 60s x 120 of which 64 were used

Binning = 1×1

Camera Temperature= 0 deg C

Camera = ZWO ASI294 MC Pro in Hyperstar Position

Filter= STC Astro Duo-Narrowband Filter

NGC 7635, also known as the Bubble Nebula, Sharpless 162, or Caldwell 11, is an H II region emission nebula in the constellation Cassiopeia. It lies close to the direction of the open cluster Messier 52. The "bubble" is created by the stellar wind from a massive hot, 8.7 magnitude young central star, SAO 20575 (BD+60°2522). The nebula is near a giant molecular cloud which contains the expansion of the bubble nebula while itself being excited by the hot central star, causing it to glow. It was discovered in 1787 by William Herschel.

Imaging Data:

Date: 6/21/2020

Exposure= 120s x 120

Binning = 1×1

Camera Temperature= 0 deg C

Camera = ZWO ASI294 MC Pro in Hyperstar Position

Filter= STC Astro Duo-Narrowband Filter

7/21/2020

The North America Nebula is large, covering an area of more than four times the size of the full moon; but its surface brightness is low, so normally it cannot be seen with the unaided eye. Binoculars and telescopes with large fields of view (approximately 3°) will show it as a foggy patch of light under sufficiently dark skies. However, using a UHC filter, which filters out some unwanted wavelengths of light, it can be seen without magnification under dark skies. Its prominent shape and especially its reddish color (from the hydrogen Hα emission line) show up only in photographs of the area.

The portion of the nebula resembling Mexico and Central America is known as the Cygnus Wall. This region exhibits the most concentrated star formation.

The North America Nebula and the nearby Pelican Nebula (IC 5070) are parts of the same interstellar cloud of ionized hydrogen (H II region). Between the Earth and the nebula complex lies a band of interstellar dust that absorbs the light of stars and nebulae behind it, and thereby determines the shape as we see it. The distance of the nebula complex is not precisely known, nor is the star responsible for ionizing the hydrogen so that it emits light. If the star inducing the ionization is Deneb, as some sources say, the nebula complex would be about 1,800 light-years' distance, and its absolute size (6° apparent diameter on the sky) would be 100 light-years.

The nebula was discovered by William Herschel, from Slough, England, on October 24, 1786 or by his son John Herschel before 1833. (Wikipedia)

Imaging Data:

Date: 7/21/20

Exposure= 60s x 316 in a 4 panel mosaic

Binning = 1×1

Gain = 120

Camera Temperature= 0 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera = ASI294MC PRO in Hyperstar position



6/19/2021 Last night I imaged IC 5070

THE PELICAN NEBULA

The Pelican Nebula (also known as IC 5070 and IC 5067) is an H II region associated with the North America Nebula in the constellation Cygnus. The gaseous contortions of this emission nebula bear a resemblance to a pelican, giving rise to its name. The Pelican Nebula is located nearby first magnitude star Deneb, and is divided from its more prominent neighbor, the North America Nebula, by a molecular cloud filled with dark dust.



The Pelican is much studied because it has a particularly active mix of star formation and evolving gas clouds. The light from young energetic stars is slowly transforming cold gas to hot and causing an ionization front gradually to advance outward. Particularly dense filaments of cold gas are seen to still remain, and among these are found two jets emitted from the Herbig–Haro object 555. Millions of years from now this nebula might no longer be known as the Pelican, as the balance and placement of stars and gas will leave something that appears completely different.

Imaging Data

Image:                        IC 5070

Date:                           6/19/2021

Exposure:                   600 sec

Number of Lights:     36 of which 18 were used for 3 hours.

Gain:                           125

Binning:                      1×1

Camera Type:            ZWO ASI294MC Pro

Cooling Temp:           -10 dec C

Filter:                          STC Astro Duo-Narrowband Filter

Telescope:                  Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                     MicroTouch Focuser

8/16/2020

Commonly known as the Lagoon Nebula, M8 was discovered in 1654 by the Italian astronomer Giovanni Battista Hodierna, who, like Charles Messier, sought to catalog nebulous objects in the night sky so they would not be mistaken for comets. This star-forming cloud of interstellar gas is located in the constellation Sagittarius and its apparent magnitude of 6 makes it faintly visible to the naked eye in dark skies. The best time to observe M8 is during August.



Located 5,200 light-years from Earth, M8 is home to its own star cluster: NGC 6530 (not visible in the image above). The massive stars embedded within the nebula give off enormous amounts of ultraviolet radiation, ionizing the gas and causing it to shine. NASA



Imaging Data

Image:                         M8

Date:                           8/14/2020

Exposure:                    30 sec

Number of Lights:       148 lights for 1H and 14M of which 69 were used for  34.5 M

Gain:                           120

Binning:                       1×1

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             0 deg C

Filter:                           STC Astro Duo-Narrowband Filter

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser

NGC 1977 is an HII region and bright nebulae that includes a reflection nebula located in the constellation Orion. It is the northernmost part of the asterism known as Orion's Sword, lying 0.6° north of the Orion Nebula.  The Running Man Nebula is a popular target for amateur astrophotographers, as it lies close to the Orion Nebula and has many nearby guide stars. The outline of the running man shows up primarily in photographs; it is difficult to perceive visually through telescopes, though the reflection nebula itself is visible in small to medium apertures in dark skies.  Wikipedia

This reflection nebula, also known as NGC 1977, is located in the constellation of Orion about 1,500 light years from Earth.  Space.com

Imaging Data:

Date Nov 29, 2020

Exposure= 10 seconds x 900 for a total exposure of 1 hour 9 minutes 30 seconds of which 41 minutes and 20 seconds were used.

Gain=120

Binning = 1×1

Camera Temperature= -10 deg C

Filter= STC Astro Duo-Narrowband Filter

Camera: ASI294MC PRO in Hyperstar configuration.



4/10/2021 LEO’S TRIPLET

The Leo Triplet, or the M66 Group, is a group of interacting spiral galaxies located in the northern constellation Leo. The group consists of the galaxies Messier 65, Messier 66 and NGC 3628, also known as the Hamburger Galaxy. The Leo Triplet lies at an approximate distance of 35 million light years from Earth.

The three large spiral galaxies can be seen in a single field of view and are well viewed even in small telescopes. Their galactic disks are tilted at different angles when seen from Earth. NGC 3628 appears edge-on, while M65 and M66 are inclined enough to reveal their spiral arms.

The M66 Group is located in the eastern part of Leo constellation, along the line from the bright star Denebola to Regulus. The galaxies are located between the stars Chertan, Theta Leonis, and Iota Leonis.

Messier 66, the largest and brightest member of the Leo Triplet, is roughly 95 light years across. It has an apparent size of 9.1 by 4.2 minutes of arc and an apparent magnitude of 8.9.

Messier 65 has a visual magnitude of 10.25 and occupies an area of 8.709 by 2.454 arc minutes of apparent sky. It is an intermediate spiral galaxy, poor in dust and gas, and shows little evidence of star formation.

NGC 3628 is an unbarred spiral galaxy with a visual magnitude of 10.2. Seen edge-on, the galaxy occupies an area of 15 by 3.6 arc minutes and appears transected by a broad band of dust that stretches along its outer edge, hiding the young stars in the galaxy’s spiral arms.

The three galaxies in the M66 Group have all been affected by gravitational interactions with each other. This is evident in the deformed, drawn out spiral arms of M66 that are experiencing a high rate of star forming activity and in the warped, inflated disk of NGC 3628. With a prominent tidal tail consisting mainly of young blue stars, NGC 3628 seems to be the most affected of the three, while M65 appears to have suffered the least damage from the interaction. The tidal tail of NGC 3628 spans over 300,000 light years, but is very faint and does not always appear in images of the galaxy. (Messier-Objects.com)

Imaging Data

Image:                         LEO’S TRIPLET

Date:                           4/10/2021

Exposure:                    30s

Number of Lights:       600 of which 307 were used for 2 hours, 33 minutes, 30 secomds

Darks:                          No

Flats:                           No

Gain:                           120

Binning:                       1×1

Imaging Software:      Sequence Generator Pro

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             -10 deg C

Filter:                           STC Astro Duo-Narrowband Filter

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser



4/18/2021 MARKARIAN’S CHAIN

I imaged this on April18th and is composed of 347 x 30 second images.

Markarian's Chain is a stretch of galaxies that forms part of the Virgo Cluster. When viewed from Earth, the galaxies lie along a smoothly curved line. Charles Messier first discovered two of the galaxies, M84 and M86, in 1781. The other galaxies seen in the chain were discovered by William Herschel and are now known primarily by their catalog numbers in John Louis Emil Dreyer's New General Catalogue, published in 1888. It was ultimately named after the Armenian astrophysicist, Benjamin Markarian, who discovered their common motion in the early 1960s. Member galaxies include M84 (NGC 4374), M86 (NGC 4406), NGC 4477, NGC 4473, NGC 4461, NGC 4458, NGC 4438 and NGC 4435. It is located at RA 12h 27m and Dec +13° 10′.

The bright members of the chain are visible through small telescopes. Larger telescopes can be used to view the fainter galaxies.

At least seven galaxies in the chain appear to move coherently, although others appear to be superposed by chance. Six of the points on the chain can be marked by galaxies. The other two points are pairs of galaxies. Wikipedia

These galaxies lie about 60 million light years away.

Imaging Data

Image:                         Markarian’s Chain

Date:                           4/18/2021

Exposure:                    30s

Number of Lights:       346

Darks:                          No

Flats:                           No

Gain:                           120

Binning:                       1×1

Imaging Software:      Sequence Generator Pro

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             -10 deg C

Filter:                           Astronomik UV/IR

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser

4/26/2012 The Virgo Cluster is a large cluster of galaxies whose center is 53.8 ± 0.3 million light years away in the constellation Virgo. Comprising approximately 1300 (and possibly up to 2000) member galaxies, the cluster forms the heart of the larger Virgo Supercluster, of which the Local Group (containing our Milky Way galaxy) is a member. Wikipedia

Imaging Data

Image:                         Markarian’s Chain

Date:                           4/17/2021

Exposure:                    30s

Number of Lights:       198 for 1 hour 39 minutes

Darks:                          No

Flats:                           No

Gain:                           120

Binning:                       1×1

Imaging Software:      Sequence Generator Pro

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             -10 deg C

Filter:                           Astronomik UV/IR

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser

NGC 4631 is a big beautiful spiral galaxy. Seen edge-on, it lies only 25 million light-years away in the well-trained northern constellation Canes Venatici. The galaxy's slightly distorted wedge shape suggests to some a cosmic herring and to others its popular moniker, The Whale Galaxy. Either way, it is similar in size to our own Milky Way. Apod.NASA.gov

Imaging Data:

Date:   3/28/2021

Exposure= 15s & 30s the final time of exposure was 1 hour 27 minutes 30 seconds

Binning = 1×1

Camera Temperature= -10 deg C

Camera Gain= 120

Filter= STC Astro Duo-Narrowband Filter

Camera: ASI294MC PRO in Hyperstar configuration.

5/27/2021

The Coma Cluster (Abell 1656) is a large cluster of galaxies that contains over 1,000 identified galaxies. Along with the Leo Cluster (Abell 1367), it is one of the two major clusters comprising the Coma Supercluster. It is located in and takes its name from the constellation Coma Berenices.

The cluster's mean distance from Earth is 99 Mpc (321 million light years).  Its ten brightest spiral galaxies have apparent magnitudes of 12–14 that are observable with amateur telescopes larger than 20 cm. The central region is dominated by two supergiant elliptical galaxies: NGC 4874 and NGC 4889. The cluster is within a few degrees of the north galactic pole on the sky. Most of the galaxies that inhabit the central portion of the Coma Cluster are ellipticals. Both dwarf and giant ellipticals are found in abundance in the Coma Cluster. Wikipedia

Imaging Data

Image:                         ABELL 1656

Date:                           5/26/2021

Exposure:                    300s

Number of Lights:       40 for 3 hours 20 minutes

Darks:                          No

Flats:                           No

Gain:                           120

Binning:                       1×1

Imaging Software:      Sequence Generator Pro

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             -10 deg C

Filter:                           STC Astro Duo-Narrowband Filter

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser

6/3/2021

NGC 6992 is the eastern half of the Veil Nebula, a supernova remnant in Cygnus. Its catalog designations are NGC 6992, NGC 6995 and IC 1340.  This bright portion of the Veil Nebula is also known as the Network Nebula. The supernova explosion that created the Veil Nebula occurred 5,000 to 10,000 years ago. It is located 1,400 to 2,500 light-years away in the constellation of Cygnus.  Hansonastronomy.com

Imaging Data

Image:                         NGC 6992

Date:                           6/3/2021

Exposure:                    300s

Number of Lights:       37 for 3 hours 5 minutes

Darks:                          Yes

Flats:                           No

Gain:                           120

Binning:                       1×1

Imaging Software:      Sequence Generator Pro

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             -10 deg C

Filter:                           STC Astro Duo-Narrowband Filter

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser

6/4/2021

IC 1318

In the constellation of the swan near the nebula of the pelican lies the gas cloud of the butterfly next to a star known as the hen. That star is given the proper name Sadr, but the central Butterfly Nebula is designated IC 1318. The intricate patterns in the bright gas and dark dust are caused by complex interactions between interstellar winds, radiation pressures, magnetic fields, and gravity. The portion of the Butterfly Nebula pictured spans about 100 light years and lies about 4000 light years away.

Imaging Data

Image:                         IC 1318

Date:                           6/4/2021

Exposure:                    300s

Number of Lights:       59 of which 11 were used for a total of 55 minutes

Darks:                          Yes

Flats:                           No

Gain:                           120

Binning:                       1×1

Imaging Software:      Sequence Generator Pro

Camera Type:              ZWO ASI294MC Pro

Cooling Temp:             -10 deg C

Filter:                           STC Astro Duo-Narrowband Filter

Telescope:                   Celestron 1100HD SCT

Mount :                       10MICRON GM1000HPS

Focuser:                      MicroTouch Focuser
